CIPP Drain Lining
CIPP drain lining creates a continuous resin liner inside a supported pipe. CCTV, cleaning, access and branch positions determine where it can be installed.
View serviceCCTV surveys, lining and targeted repair
Drain Relining Services
A local crack may suit a patch while repeated damage through a sound run may justify a full liner. Current CCTV, pipe condition, defect length and access decide the repair route.
Service details
Drain repair scope
Name the affected drain and describe what has been happening. Include CCTV footage if you already have it.
Include the affected pipe, current symptoms, available CCTV and the nearest workable access point.
No-Dig Drain Repair
No-dig drain repair can treat suitable buried damage through existing access points, although collapse, severe displacement or an unusable route can still require excavation.
View serviceStart with the fault, not a product name
Tell us which outlets are affected, whether the problem returns and what is above the buried run. Existing footage can help, but you do not need to interpret it or choose a lining system before defining the scope.
Our services
The work can include fault-finding, root or scale removal, a local patch, a continuous resin liner or a focused excavation. Each deals with a different condition inside the drain.
- ✓Locate the defect from a known chamber
- ✓Check access and cleaning needs
- ✓Match the repair to the visible pipe
- ✓State the handover records in the quotation
How it works
What happens during a drain lining job
The repair company locates the fault, removes material that would interfere with the lining and prepares the selected resin system. It controls drainage use while the material cures, deals with branches inside the repaired run and checks the pipe before returning it to service.
Ask us to inspect your drain
SURVEY / PREPARE / REPAIR
When lining may be suitable
The cleaned pipe must retain a usable route and enough support for the selected liner.
- Find the full extent of the faultTrace the damaged area and look beyond it so a local crack is not confused with a failing run.
- Expose the pipe wallRemove roots, grease, scale or debris with tools suited to the material underneath.
- Install the chosen repairPosition one patch over a contained fault or use a continuous liner for damage through a longer section.
- Reopen and return to useDeal with planned branches, remove the equipment and confirm when normal drainage use can resume.
Problems we can help with
Cracks, roots, movement and failed pipe
A returning blockage might be roots entering one joint, waste catching on an offset or a pipe flattening under load. Damp can come from a crack or failed connection. Finding the cause prevents the wrong repair being sold for the symptom.
Who we work with
Plan the repair around the people using the drain
A household may need its only bathroom back quickly; a school must separate equipment from pupil routes; a factory must control process discharge. The pipe repair and the site's operating plan have to work together.
Repair sequenceFrom pipe evidence to a repair decision
Drain relining
A no-dig repair still depends on the pipe condition
Clear CCTV must show a stable route through the damaged section. A collapsed pipe or one that has lost its support needs direct access instead.
Repair sequence
From CCTV evidence to completed liner
Survey the cleaned pipe, prepare the host surface, install the specified repair and check the result against the original defect.
Survey the pipe
Locate the defect from a known chamber and record the surrounding host-pipe condition.
Prepare the repair length
Remove roots, scale and deposits, then confirm the bore and connections that must remain open.
Install and cure
Position the patch or full liner and control the curing process for the specified system.
Record the result
Use post-work CCTV to show the repaired limits, reopened connections and any remaining defect.
Drain relining advice
Answers about surveys, liners and repairs
Read about common pipe faults, CCTV surveys and the differences between patch lining, full-length lining and excavation.
Drain Relining Cost
Drain relining cost depends on the measured repair, preparation, access and connection work. Quotations are useful only when they price the same scope.
Read guidanceCan This Drain Be Relined?
A drain can be relined when the damaged section remains supported and the installation equipment can reach it. Clean CCTV is the starting evidence.
Read guidanceShould This Drain Be Lined or Excavated?
Drain relining and excavation correct different kinds of failure. The comparison should be based on the surveyed defect, access and reinstatement required.
Read guidanceDrain Relining and Insurance Claims
Drain relining and insurance claims involve separate technical and policy decisions. Keep the survey, proposed repair and insurer's requirements clearly recorded.
Read guidanceQuestions about the work
Drain relining FAQs
These answers cover the choices customers commonly face when a buried drain is cracked, rooted or no longer holding its shape.
Can you repair a drain without digging?+
Often, if a patch or liner can reach a supported section of pipe. Collapse, lost alignment or a broken connection may still need a focused opening.
Why inspect the pipe first?+
The same symptom can come from roots, movement, scale or a fracture. Seeing the cause prevents a lining method being chosen for the wrong fault.
Can relining deal with tree roots?+
The roots are removed first. The opening beneath them can then be sealed internally if the surrounding pipe will support the repair.
What should be handed over?+
Ask the company carrying out the work to identify the treated section, the repair installed, any connection work and points that still need attention.
